Features
- Bass reflex speaker with a 12'' LF woofer and 44mm HF compression driver
- Frequency response 50Hz-20kHz(-3dB)
- Coverage 80°x50°
- Sensitivity 97dB, max. SPL 118dB/124dB(peak)
- Rated power 300W, 1200W in peak.
- 26 x M10 rigging points for easy and quick installation.
Specifications
Acoustical specifications
Frequency Response(-3db):
50Hz-20kHz
Max SPL @ 1m:
118dB/124dB(PEAK)
Dispersion (H x V):
80° x 50°
Transducers
Compression driver:
1 x 3" HF
Woofer:
1 x 12" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
97dB
Processor section
Crossover frequencies:
2.1kHz
Power section
Total Power:
300W(RMS); 600W(MUSIC); 1200W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
15mm Birch Plywood
Color:
Black
Size
Dimension (W x D x H):
350 x 430 x 630mm / (13.8 x 16.9 x 24.8in)
Package Dimensions (W x D x H):
520 x 440 x 730mm / (20.5 x 17.3 x 28.7in)
Weight
Net Weight:
23 kg / 50.7 lb
Gross Weight:
25 kg / 55.1 lb
