Features
- Built in 70W @ 8ohm amplifier
- Reach a peak of 141dB/1m for warning
- Built-in two internal lithium batteries (7800mA/12V) provides at least 6 hours of ontinuous broadcast time.
- The on-board battery charger satisfies quickly battery charging.
- Water and dust resistance for outdoor use (IP45)
- Achieving 85% speech intelligibility at 1000 meters
- Heavy duty plastic enclosure
- Design for use in search rescue, patrol, police crowd control, arm force, school, tc
Specifications
Acoustical specifications
Frequency Response(-3db):
300Hz-5kHz
Max SPL @ 1m:
100dB (PEAK, 100m), 141dB(PEAK, 1m)
Dispersion (H x V):
80° x 50°
Transducers
Compression driver:
1 x 2" HF
Input/Output section
Power section
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
227 x 380 x 397mm / (8.9 x 15 x 15.6in)
Package Dimensions (W x D x H):
430 x 290 x 460mm / (16.9 x 11.4 x 18.1in)
Weight
Net Weight:
8.5 kg / 18.7 lb
Gross Weight:
10 kg / 22 lb
db100Ⅱ Application
db100Ⅱ Installation
db100Ⅱ Parts
db100Ⅱ Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 db100Ⅱ Datasheet | 1.0 |  | 200KB | 2024-12-22 08:59:19 |
