Features
- Bass reflex speaker with a 10'' LF woofer and a 44mm HF compression driver
- Coverage 100° x 80°
- Sensitivity 94dB, max. SPL 117dB/123dB(peak)
- Rated power 200W, 800W in peak.
- Specilized rigging system for easy and quick installing and dismounting.
Specifications
Acoustical specifications
Frequency Response(-3db):
70Hz-20kHz
Max SPL @ 1m:
115dB/121dB(PEAK)
Dispersion (H x V):
130° x 110°
Transducers
Compression driver:
1 x 1.7" HF
Woofer:
1 x 10" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
94dB
Processor section
Crossover frequencies:
2.0kHz
Power section
Total Power:
150W(RMS); 300W(MUSIC); 600W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
15mm Birch Plywood
Color:
Black
Size
Dimension (W x D x H):
300 x 365 x 550mm / (11.8 x 14.4 x 21.7in)
Package Dimensions (W x D x H):
455 x 390 x 650mm / (17.9 x 15.4 x 25.6in)
Weight
Net Weight:
16.7 kg / 36.8 lb
Gross Weight:
18.8 kg / 41.4 lb
Milano110 Application
Milano110 Installation
Milano110 Parts
Milano110 Cases
Milano110 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 Milano110 Datasheet | 1.0 |  | 200KB | 2024-11-05 16:55:15 |
