Features
- High output SPL and sensitivity
- 1 x 15” high power low frequency transducer
- Heavy duty protective grill
- Injection molded
- Built-in power amplifier module
- Master volume control
- XLR input and output connectors
- Built in variable high cut filter
- Cabinet design for FOH
- Suitable for use with any full range or mid/high speaker cabinets for extended low frequency, high quality music reproduction
- Integral 35mm pole receptacle for mounting full range or mid/high speaker cabinet
Specifications
Acoustical specifications
Frequency Response(-3db):
80Hz-250Hz
Max SPL @ 1m:
120dB
Transducers
Woofer:
1 x 15" LF
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
2 x XLR
Power section
Total Power:
400W(RMS); 800W(MUSIC); 1600W(PEAK);
Nominal Impedance (Ohm):
4Ω
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
485 x 460 x 700mm / (19.1 x 18.1 x 27.6in)
Package Dimensions (W x D x H):
545 x 515 x 800mm / (21.5 x 20.3 x 31.5in)
Weight
Net Weight:
30.5 kg / 67.2 lb
Gross Weight:
33.7 kg / 74.3 lb
