Features
- Compact and light weight design, unique appearance
- Heavy duty protective grill
- 35mm pole adaptor system allow vertical application or dispersion 5 degree downward
- Integrated Monitor free feet allow the easy stage monitor application
- M8 rigging points(available for full range models) are very convenient for ifferent installation
Specifications
Acoustical specifications
Frequency Response(-3db):
45Hz-17kHz
Max SPL @ 1m:
119dB/125dB(PEAK)
Dispersion (H x V):
90° x 60°
Transducers
Compression driver:
1 x 1.7" HF
Woofer:
1 x 15" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
96dB
Power section
Total Power:
300W(RMS); 600W(MUSIC); 1200W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
Polypropylene injection moulding
Hardware:
8 x M8 hanging point, SMART pole mount system
Handles:
One side, one rear
Grille:
Powered coated grill
Color:
Black
Size
Dimension (W x D x H):
462 x 397 x 780mm / (18.2 x 15.6 x 30.7in)
Package Dimensions (W x D x H):
528 x 480 x 865mm / (20.8 x 18.9 x 34.1in)
Weight
Net Weight:
26.8 kg / 59.1 lb
Gross Weight:
28.5 kg / 62.8 lb
T15 Application
T15 Installation
T15 Parts
T15 Cases
T15 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 T15 Datasheet | 1.0 |  | 200KB | 2024-11-14 09:12:52 |
| β3_T15_Plastic_Speaker_Chinese_Manual | 1 |  | 1817.02KB | 2018-07-12 02:25:39 |
| β3_T15_Plastic_Speaker_English_Manual | 1 | | 1693.52KB | 2018-07-12 02:25:39 |
