Features
- Integrated speaker management processor
- Three-way stereo or six-way mono crossover
- 32 bit floating point DSP and digital filter
- 2 x input XLRs + 6 x Output XLRs + 2 x RS485 XLR + USB + 1 x 6.35mm socket (BGM signal)
- Software programmable via PC (USB port)
- Provides input selection, gain control, delay, crossover, equalization and limiter functions
- DSP - 64kHz sample rate with 24bit AD/DA processing
- Front panel input and output LED indicators
- Store up to 20 presets
Specifications
| Input Connector | 2 x Balanced XLR, 1 x RS485, 1 x USB + 1 x 6.35mm |
| Output Connector | 6 x Balanced XLR, 1 x RS485 |
| Input Impedance | Balanced10kΩ |
| Maximum Output Levels | +20dBu |
| A/D Sampling Rate | 64kHz, 24bit linear |
| Frequency Response (±0.3dB) | 20Hz-20kHz(+0.3/-0.3dB), 10Hz-30khz(+0.3/-3.0dB) |
| THD + N | <0.006% |
| S/N Ratio (A weight) | 110dB (A Weight) |
| Dynamic Range (A weight) | ≥107dB |
| Power Supply | AC 110V-120V~, 50/60Hz |
| Dimensions (W x D x H) | 483mm (19”) x 228mm (10”) x 45mm (1.8”) |
| Net Weight (1 piece/pack) | 4.7kg (10.4lb) |
| Gross Weight (1 piece/pack) | 6.3kg (13.9lb |
