Features
- Vertical line array of 4 x 4" LF driver
- 44mm compression driver loaded with wave guide
- Frequency response 160Hz-20kHz(-3dB)
- Sensitivity 88dB, MaxSPL 109dB
- 150 x 30 degree controlled coverage pattern
- Birch plywood construction
- Durable Polyurethane textured base paint
- Quick install U bracket included with multiple mounting points provided
- Designed for high speech intelligibility and natural sounding music
- Optional MU404 hanging hardware
Specifications
Acoustical specifications
Frequency Response(-3db):
100Hz-20kHz
Max SPL @ 1m:
109dB/115dB(PEAK)
Dispersion (H x V):
150° x 30°
Transducers
Compression driver:
1 x 44mm HF
Woofer:
4 x 4" LF
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
4-screw termina, 2 x XLR
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
15mm birch plywood
Hardware:
6 x M8
Grille:
White Polyurethane painting for cabinet & White Powder coated grille.
Color:
White
Size
Dimension (W x D x H):
144 x 692 x 235mm / (5.7 x 27.2 x 9.3in)
Package Dimensions (W x D x H):
215 x 772 x 235mm / (8.5 x 30.4 x 9.3in)
Weight
Net Weight:
10 kg / 22 lb
Gross Weight:
11 kg / 24.3 lb
