Features
- Active speaker with 4" woofers and 1" tweete
- New generation Class-D amplification for MF /LF, Class-AB for HF
- Frequency response(-3dB) 100Hz-20kHz
- Sensitivity 87dB, Maximum SPL 100dB
- Dispersion(HxV)90°x90°
- Rated Power 50W(RMS)
- Birch Plywood Construction
- Durable Polyurethane textured base paint
- Quick install U bracket included with multiple mounting points provided
- Designed for high speech intelligibility and natural sounding music
- Optional MU401 a hanging hardware
- Dedicated STAND-BY switching mode for green energy saving
Specifications
Acoustical specifications
Frequency Response(-3db):
160Hz-20kHz
Max SPL @ 1m:
100dB/106dB(PEAK)
Dispersion (H x V):
90° x 90°
Transducers
Compression driver:
1 x 25mm HF
Woofer:
1 x 4" LF
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
4-screw termina, 2 x XLR
Power section
Total Power:
50W(RMS); 100W(MUSIC); 200W(PEAK);
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
15mm birch plywood
Hardware:
6 x M8
Grille:
White Polyurethane painting for cabinet & White Powder coated grille.
Color:
White
Size
Dimension (W x D x H):
144 x 214 x 146mm / (5.7 x 8.4 x 5.7in)
Package Dimensions (W x D x H):
195 x 276 x 195mm / (7.7 x 10.9 x 7.7in)
Weight
Net Weight:
3 kg / 6.6 lb
Gross Weight:
4 kg / 8.8 lb
MU401a Application
MU401a Installation
MU401a Parts
MU401a Cases
MU401a Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 MU401a Datasheet | 1.0 |  | 200KB | 2024-11-22 13:28:46 |
