Features
- Frequency response(-3dB)100Hz-20kHz
- Sensitivity 87dB, Maximum SPL 100dB
- Dispersion(HxV) 90°x90°
- Rated Power 20W(RMS), 80W(Peak)
- Birch Plywood Construction
- Durable Polyurethane textured base paint
- Quick install U bracket included with multiple mounting points provided
- Designed for high speech intelligibility and naturalsounding music
- Optional MU401 hanging hardware
Specifications
Acoustical specifications
Frequency Response(-3db):
160Hz-20kHz
Max SPL @ 1m:
100dB/106dB(PEAK)
Dispersion (H x V):
90° x 90°
Transducers
Compression driver:
1 x 25mm HF
Woofer:
1 x 4" LF
Input/Output section
Input Connectors:
4-screw termina, 2 x XLR
Sensitivity (1W @ 1m):
87dB
Processor section
Crossover frequencies:
3.8kHz
Power section
Total Power:
20W(RMS); 40W(MUSIC); 80W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
15mm birch plywood
Hardware:
6 x M8
Grille:
White Polyurethane painting for cabinet & White Powder coated grille.
Color:
White
Size
Dimension (W x D x H):
144 x 214 x 146mm / (5.7 x 8.4 x 5.7in)
Package Dimensions (W x D x H):
195 x 276 x 195mm / (7.7 x 10.9 x 7.7in)
Weight
Net Weight:
3 kg / 6.6 lb
Gross Weight:
4 kg / 8.8 lb
MU401 Application
MU401 Installation
MU401 Parts
MU401 Cases
MU401 Collocation
Videos
Downloads
Filename | Version | Language | Size | Updated |
β3 MU401 Datasheet | 1.0 | 200KB | 2024-12-25 10:01:15 |
