Features
Ultra high output and excellent low-frequency performance
Adopting a built-in low-frequency divider design, the sound quality is more natural, delicate, and pleasant to listen to.
D-class high-power amplifier module
High power voice coil long stroke direct radiation low-frequency unit
Exquisite, professional, and elegant appearance has perfect performance in any application situation
Sturdy spray painted wooden box for long-lasting durability
Sound quality characteristics: clean, powerful, and not losing elasticity.
Specifications
Acoustical specifications
Frequency Response(-3db):
37Hz-200Hz
Max SPL @ 1m:
134dB/140dB(PEAK)
Transducers
Woofer:
1 x 18" Subwoofer
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
1 x XLR
Power section
Total Power:
1300W(RMS); 2600W(MUSIC); 5200W(PEAK);
Nominal Impedance (Ohm):
4Ω
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
18mm Plywood
Handles:
2 × Wooden handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
550 x 718 x 850mm / (21.7 x 28.3 x 33.5in)
Package Dimensions (W x D x H):
820 x 650 x 970mm / (32.3 x 25.6 x 38.2in)
Weight
Net Weight:
61 kg / 134.5 lb
Gross Weight:
67 kg / 147.7 lb
