Features
Ultra high output and excellent low-frequency performance
Adopting a built-in low-frequency divider design, the sound quality is more natural, delicate, and pleasant to listen to.
D-class high-power amplifier module
High power voice coil long stroke direct radiation low-frequency unit
Exquisite, professional, and elegant appearance has perfect performance in any application situation
Sturdy spray painted wooden box for long-lasting durability
Sound quality characteristics: clean, powerful, and not losing elasticity.
Specifications
Acoustical specifications
Frequency Response(-3db):
45Hz-250Hz
Max SPL @ 1m:
121dB/127dB(PEAK)
Transducers
Woofer:
1 x 12" Subwoofer
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
1 x XLR
Power section
Total Power:
380W(RMS); 760W(MUSIC); 1520W(PEAK);
Nominal Impedance (Ohm):
4Ω
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
15mm Plywood
Handles:
2 × Wooden handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
450 x 465 x 370mm / (17.7 x 18.3 x 14.6in)
Package Dimensions (W x D x H):
565 x 565 x 490mm / (22.2 x 22.2 x 19.3in)
Weight
Net Weight:
22 kg / 48.5 lb
Gross Weight:
24.5 kg / 54 lb
