Features
- Integrating high performance into a 1U compact body, easily meeting various installation scenarios
- Adopting switch mode power supply and class-D power amplifier design to ensure safety and reliability
- Provide 4-channel and 8-channel designs for more flexible options
- Each channel is independently configured with volume control, making audio output easy to control
- Power (protection), signal, and clipping are equipped with LED displays to ensure that everything is under control
- Significantly reduce work energy consumption and inject green energy into your audio system
- Professional and efficient, safe and reliable, providing you with excellent sound effects
Specifications
RMS Stereo Power(8ohms):
8 x 150W
RMS Stereo Power(4ohms):
8 x 250W
Input Sensitivity:
1Vrms
S/N Ratio:
>94dB
Frequency Response:
20Hz~20kHz ( ±2dB )
Power Supply Specifications:
~100-240V 50Hz/60Hz
Dimension (W x D x H):
483 x 45.5 x 260mm / (19 x 1.8 x 10.2in)
Net Weight:
5.1 kg / 11.2 lb
DA1508 Application
DA1508 Installation
DA1508 Parts
DA1508 Cases
DA1508 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 DA1508 Datasheet | 1.0 |  | 200KB | 2024-12-21 16:57:11 |
