Features
- Integrating high performance into a 1U compact body, easily meeting various installation scenarios
- Adopting switch mode power supply and class-D power amplifier design to ensure safety and reliability
- Provide 4-channel and 8-channel designs for more flexible options
- Each channel is independently configured with volume control, making audio output easy to control
- Power (protection), signal, and clipping are equipped with LED displays to ensure that everything is under control
- Significantly reduce work energy consumption and inject green energy into your audio system
- Professional and efficient, safe and reliable, providing you with excellent sound effects
Specifications
RMS Stereo Power(8ohms):
4 x 150W
RMS Stereo Power(4ohms):
4 x 250W
Input Sensitivity:
1Vrms
S/N Ratio:
>94dB
Frequency Response:
20Hz~20kHz ( ±2dB )
Power Supply Specifications:
~100-240V 50Hz/60Hz
Dimension (W x D x H):
483 x 45.5 x 260mm / (19 x 1.8 x 10.2in)
Net Weight:
4.2 kg / 9.3 lb
DA1504 Application
DA1504 Installation
DA1504 Parts
DA1504 Cases
DA1504 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 DA1504 Datasheet | 1.0 |  | 200KB | 2025-02-22 01:44:18 |
