DD420NF

Professional digital network power amplifier



Features

  • Compact 1U body with a stable and ultra lightweight structure.
  • 3.3 inch LCD display screen for more intuitive operation.
  • Excellent sound quality, equipped with high-performance audio dedicated DSP.
  • Supports Dante digital audio signal transmission.
  • 4x4 audio routing matrix.
  • Support importing and exporting 512 order FIR filter parameters per channel.
  • Modular design, simple and easy to maintain, ensuring long-term reliable performance.
  • Safe and controllable, power amplifier monitoring is achieved through a single network cable, allowing for quick local diagnosis.

Specifications

RMS Stereo Power(8ohms):
4 x 2000W
RMS Stereo Power(4ohms):
4 x 3400W
RMS Stereo Power(2ohms):
4 x 4760W
RMS Bridge Power(16ohms):
2 x 4000W
RMS Bridge Power(8ohms):
2 x 6800W
RMS Bridge Power(4ohms):
2 x 9520W
S/N Ratio:
44.7V
Frequency Response:
20Hz~20kHz ( ±2dB )
Power Supply Specifications:
90~260VAC,50/60Hz
Dimension (W x D x H):
483 x 45 x 370mm / (19 x 1.8 x 14.6in)
Net Weight:
9 kg / 19.8 lb

DD420NF Application

    DD420NF Installation

      DD420NF Parts

        DD420NF Cases

          DD420NF Collocation

            Videos

              Downloads

              FilenameVersionLanguageSizeUpdated
              DD420NFβ3 DD420NF Datasheet 1.0DD420NF  200KB 2024-12-22 21:09:40
