Features
- Dual 4-inch woofers and 5 silk-dome tweeters
- Made of plastic ABS material, lightweight, strong and durable.
- The modular structure design allows it to be flexibly combined and matched according to needs.
- Small size and easy to use.
Specifications
Acoustical specifications
Frequency Response(-3db):
85Hz-20kHz
Max SPL @ 1m:
107dB/113dB (PEAK)
Dispersion (H x V):
100° x 0-5°
Transducers
Compression driver:
5 x 16mm silk dome tweeter
Woofer:
2 x 4" woofer
Input/Output section
Input Connectors:
Phonix Connectors
Sensitivity (1W @ 1m):
90dB
Power section
Total Power:
50W(RMS); 100W(MUSIC); 200W(PEAK);
Nominal Impedance (Ohm):
16Ω
Physical specifications
Grille:
Cabinet is etched with fine lines, and the surface is covered with light gray mesh fabric through pl
Color:
White
Size
Dimension (W x D x H):
335 x 196 x 148mm / (13.2 x 7.7 x 5.8in)
Package Dimensions (W x D x H):
415 x 270 x 235mm / (16.3 x 10.6 x 9.3in)
Weight
Net Weight:
3.7 kg / 8.2 lb
Gross Weight:
4.5 kg / 9.9 lb
