Features
- Designed with a high dynamic woofer and papercone driver for exceptional sound quality.
- Constructed with a polypropylene molding cabinet for durability.
- Point source design perfecty replay the vocal and music.
- Includes a three-channel mixer with independent EQ adjustments for instrument and microphone channels, as well as AUX/Bluetooth connectivity.
- Multiple atmosphere modes with ambient light can be adjusted to create the desired mood.
- Bluetooth 5.0 allows for stereo setup.
- Features a large capacity rechargeable battery, providing 8 hours of playtime per charge.
- Can be used as an installation or monitor speaker.
Specifications
Acoustical specifications
Frequency Response(-3db):
60Hz-20kHz
Max SPL @ 1m:
113dB/119dB(PEAK)
Dispersion (H x V):
80° x 80°
Transducers
Compression driver:
1 x 1.4" HF
Woofer:
1 x 12" LF
Input/Output section
Input Connectors:
2 x 1/4", 1/8", Bluetooth and Main in (1/4")
Power section
Total Power:
250W(RMS); 500W(MUSIC); 1000W(PEAK);
Voltage range:
AC 110V/230V, 50Hz/60Hz
Physical specifications
Handles:
1 x Plastic handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
440 x 542 x 374mm / (17.3 x 21.3 x 14.7in)
Package Dimensions (W x D x H):
480 x 588 x 410mm / (18.9 x 23.1 x 16.1in)
Weight
Net Weight:
15 kg / 33.1 lb
Gross Weight:
18 kg / 39.7 lb
R12P Application
R12P Installation
R12P Parts
R12P Cases
R12P Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 R12P Datasheet | 1.0 |  | 200KB | 2024-12-21 14:37:43 |
