Features
- Designed with a high dynamic woofer and papercone driver for exceptional sound quality.
- Constructed with a polypropylene molding cabinet for durability.
- Point source design perfecty replay the vocal and music.
- Includes a three-channel mixer with independent EQ adjustments for instrument and microphone channels, as well as AUX/Bluetooth connectivity.
- Multiple atmosphere modes with ambient light can be adjusted to create the desired mood.
- Bluetooth 5.0 allows for stereo setup.
- Features a large capacity rechargeable battery, providing 8 hours of playtime per charge.
- Can be used as an installation or monitor speaker.
Specifications
Acoustical specifications
Frequency Response(-3db):
70Hz-15kHz
Max SPL @ 1m:
106dB/112dB(PEAK)
Dispersion (H x V):
120° x 80°
Transducers
Compression driver:
1 x 3" HF
Woofer:
1 x 10" LF
Input/Output section
Input Connectors:
2 x 1/4", 1/8", Bluetooth and Main in (1/4")
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Voltage range:
AC 110V/230V, 50Hz/60Hz
Physical specifications
Handles:
1 x Plastic handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
376 x 464 x 316mm / (14.8 x 18.3 x 12.4in)
Package Dimensions (W x D x H):
435 x 375 x 525mm / (17.1 x 14.8 x 20.7in)
Weight
Net Weight:
10.5 kg / 23.1 lb
Gross Weight:
12 kg / 26.5 lb
