Features
- Ultra-compact battery-powered portable PA system
- 8 -inch woofer with coaxial driver
- Three discrete input channels w/individual Volume and Tone controls
- Bluetooth streaming enabled on Channel 3
- Integrated digital effects processor
- Battery life LED indicator
- 8 hour battery life per charge
- Multiple display positions including vertical tilt, horizontal wedge, table top, and more
- Integrated standard speaker stand mount
Specifications
Acoustical specifications
Frequency Response(-3db):
60Hz-20kHz
Max SPL @ 1m:
110dB/116dB(PEAK)
Dispersion (H x V):
90° x 90°
Transducers
Compression driver:
1 x 5" HF
Woofer:
1 x 8" LF
Input/Output section
Input Connectors:
XLR/TRS
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Nominal Impedance (Ohm):
LF：2Ω，HF：4Ω
Cooling:
Natural air cooling
Power consumption(static):
32W
Voltage range:
AC 100V/240V, 50Hz/60Hz
Physical specifications
Cabinet/Case Material:
Plastic box
Handles:
1 x Plastic handle
Grille:
The surface of the box is black etched, and the surface of the mesh is black powdered
Color:
Black
Size
Dimension (W x D x H):
259 x 292 x 390mm / (10.2 x 11.5 x 15.4in)
Package Dimensions (W x D x H):
360 x 330 x 465mm / (14.2 x 13 x 18.3in)
Weight
Net Weight:
7.5 kg / 16.5 lb
Gross Weight:
8.8 kg / 19.4 lb
MB3 Application
MB3 Installation
MB3 Parts
MB3 Cases
MB3 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 MB3 Datasheet | 1.0 |  | 200KB | 2024-11-21 12:37:16 |
| β3_Meline_MB3_PA_English_Manual | 1 | | 2927KB | 2022-11-24 13:48:40 |
| β3_Meline_MB3_PA_Chinese_Manual | 1 |  | 2968KB | 2022-11-24 13:48:04 |
