Features
- 2-way small full-range speaker.
- A 10-inch high-sensitivity Cloth edge woofer,
- a φ34mm tweeter titanium diaphragm driver.
- New rotatable tweeter horn. Waterproof case. There are suspension mounting points around the speaker.
- Mid and treble are transparent and clear, with good vocal performance, and can interpret all kinds of music.
- Suitable for cultural tourism, water features, music fountains and other places
Specifications
Acoustical specifications
Frequency Response(-3db):
55Hz-18kHz
Max SPL @ 1m:
119dB/125dB(PEAK)
Dispersion (H x V):
90° x 90°
Transducers
Compression driver:
1 x 1.3" HF
Woofer:
1 x 10" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
95dB
Power section
Total Power:
250W(RMS); 500W(MUSIC); 1000W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
321 x 321 x 464mm / (12.6 x 12.6 x 18.3in)
Package Dimensions (W x D x H):
375 x 355 x 535mm / (14.8 x 14 x 21.1in)
Weight
Net Weight:
15.5 kg / 34.2 lb
Gross Weight:
17.5 kg / 38.6 lb
