Features
- Refraining the whistle
- Automatic selection for signal sources
- Available for KTV Room
- Available for connecting 3 groups speaker simultaneously
- Built-in vocal embellishment circuit, make the sound rich & natural
- Built-in strong refrigerant fan for ventilation to meet for a long period of time working.
Specifications
Rated Power (RMS) | 200W+200W+200W(1KHz,8Ohm) |
| THD (@1kHz) | 0.02% (1KHz,100W,8Ohm) |
| Frequency Response(-3dB | 20Hz-20kHz±2dB |
| Input Sensitivity/Impedance | MIC: 20mV/2kΩ Line: 200mV/10kΩ Video: 1Vp-p/75Ohm |
Pitch Control | Music: LF(100Hz) ±10dB HF(10KHz) ±10dBMIC: LF(100Hz) ±10dB HF(10kHz) ±10dB |
| Effect Type | Echo |
| Pitch change control | ±4 |
| Output Impedance | 4-16Ω |
| Recommendatory Impedance | 8Ω |
| Power Supply | ~110V/~220V,50Hz |
| Power Consumption | ＜1000W |
| AC output socket | One group with switch: 200W Two groups without switch: 300W |
| Static Power Consumption | 30W |
| Net Weight (1 pc) | 12.5kg |
| Gross Weight (1 pc) | 14.0kg |
| Dimension(W×D×H) | 505x435x200(mm) |
AK3200 Application
AK3200 Installation
AK3200 Parts
AK3200 Cases
AK3200 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 AK3200 Datasheet | 1.0 |  | 200KB | 2024-11-15 06:21:36 |
