Features
- Curve technology for fixed point attenuation control
- Hi-Fi class vocal speaker, features specified high efficient karaoke speakers.
- Hi-Fi blue ray cone paper makes LF soft
- Computer aided design to optimize frequency and phase response
- Self-recovery protective component to protect HF
Specifications
Acoustical specifications
Frequency Response(-3db):
45Hz-19kHz
Max SPL @ 1m:
121dB
Transducers
Compression driver:
4 x 3" HF
Woofer:
1 x 10" LF
Input/Output section
Sensitivity (1W @ 1m):
92dB
Processor section
Crossover frequencies:
1.3kHz
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
502 x 270 x 292mm / (19.8 x 10.6 x 11.5in)
Package Dimensions (W x D x H):
655 x 360 x 570mm / (25.8 x 14.2 x 22.4in)
Weight
Net Weight:
10.5 kg / 23.1 lb
Gross Weight:
23 kg / 50.7 lb
F10D Application
F10D Installation
F10D Parts
F10D Cases
F10D Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 F10D Datasheet | 1.0 |  | 200KB | 2025-02-22 15:12:16 |
