Features
- Curve technology for fixed point attenuation control
- Computer aided design to optimize frequency and phase response
- Self-recovery protective component to protect HF
Specifications
Acoustical specifications
Frequency Response(-3db):
60Hz-20kHz
Max SPL @ 1m:
109dB
Transducers
Compression driver:
2 x 3" HF
Woofer:
1 x 8" LF
Input/Output section
Sensitivity (1W @ 1m):
89dB
Processor section
Crossover frequencies:
2.0KHz
Power section
Total Power:
100W(RMS); 200W(MUSIC); 400W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
430 x 255 x 255mm / (16.9 x 10 x 10in)
Package Dimensions (W x D x H):
600 x 325 x 530mm / (23.6 x 12.8 x 20.9in)
Weight
Net Weight:
8 kg / 17.6 lb
Gross Weight:
18 kg / 39.7 lb
