Features
- High Sensitivity LF passive speaker
- 1x15” LF transducer
- High strength cabinet structure
- Powder coated grill
- Computer aided design to optimize frequency and phase response
- suitable for use as a main system with TH306/64 or TH306/96
- Durable Polyurethane textured base paint
- suitable for theatre ,television studio, multi-functional room and performance tudio
Specifications
Acoustical specifications
Frequency Response(-3db):
65Hz-1kHz
Max SPL @ 1m:
117dB/123dB(PEAK)
Transducers
Woofer:
1 x 15" LF
Input/Output section
Input Connectors:
1 x NL4 + binding post
Sensitivity (1W @ 1m):
97dB
Power section
Total Power:
450W(RMS); 900W(MUSIC); 1800W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
520 x 520 x 520mm / (20.5 x 20.5 x 20.5in)
Package Dimensions (W x D x H):
630 x 630 x 640mm / (24.8 x 24.8 x 25.2in)
Weight
Net Weight:
24.5 kg / 54 lb
Gross Weight:
36.5 kg / 80.5 lb
TH115L Application
TH115L Installation
TH115L Parts
TH115L Cases
TH115L Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 TH115L Datasheet | 1.0 |  | 200KB | 2024-12-21 22:01:34 |
| β3_TH306H-64_TH306H-94_TH115L_PA_Chinese_Manual | 1 |  | 1207.11KB | 2018-07-12 02:25:39 |
| β3_TH306H-64_TH306H-94_TH115L_PA_English_Manual | 1 | | 958.96KB | 2018-07-12 02:25:39 |
