Features
- High Sensitivity subwoofer.
- 2x18” high efficient LF driver.
- High strength cabinet structure
- Computer aided design to optimize frequency and phase response.
- Powder coated grill
- Durable Polyurethane textured base paint
- suitable for theatre, large multifunctional hall, auditorium, live performance sound reinforcement.
Specifications
Acoustical specifications
Frequency Response(-3db):
38Hz-1kHz
Max SPL @ 1m:
134dB/140dB(PEAK)
Transducers
Woofer:
2 x 18" LF
Input/Output section
Input Connectors:
1 x NL4 + binding post
Sensitivity (1W @ 1m):
103dB
Power section
Total Power:
1200W(RMS); 2400W(MUSIC); 4800W(PEAK);
Nominal Impedance (Ohm):
4Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
567 x 750 x 1075mm / (22.3 x 29.5 x 42.3in)
Package Dimensions (W x D x H):
1185 x 860 x 685mm / (46.7 x 33.9 x 27in)
Weight
Net Weight:
74 kg / 163.1 lb
Gross Weight:
80 kg / 176.4 lb
