Features
- High SPL and High Sensitivity low frequency system
- 1x15” high power subwoofer
- High strength cabinet structure
- suitable for use as a main system with TH306/64 or TH306/93
- Computer aided design to optimize frequency and phase response
- Powder coated grill
- Durable Polyurethane textured base paint
- suitable for theatre ,television studio, multi-functional room and performance tudio
Specifications
Acoustical specifications
Frequency Response(-3db):
40Hz-19kHz
Max SPL @ 1m:
Passive: 116dB/122dB(PEAK); Bi-amp: MF: 116dB/122dB(PEAK),HF: 114dB/120dB(PEAK)
Dispersion (H x V):
TH215H/64: 60°x 40°; TH215H/96: 90°x 60°
Transducers
Compression driver:
1 x 44mm HF
Woofer:
1 x 15" LF
Input/Output section
Input Connectors:
1 x NL8, 8-way binding post
Sensitivity (1W @ 1m):
Passive: 98dB; Bi-amp: LF: 97dB; HF: 107dB
Processor section
Crossover frequencies:
1.5kHz-2.5kHz
Power section
Total Power:
350W(RMS); 700W(MUSIC); 1400W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Hardware:
19 x M10
Color:
Black
Size
Dimension (W x D x H):
440 x 470 x 680mm / (17.3 x 18.5 x 26.8in)
Package Dimensions (W x D x H):
580 x 550 x 800mm / (22.8 x 21.7 x 31.5in)
Weight
Net Weight:
28 kg / 61.7 lb
Gross Weight:
31.5 kg / 69.4 lb
