Features
- High SPL and High Sensitivity two way mid/high system
- 1x6”MF 1x1.75”HF compressed driver
- High strength cabinet structure
- suitable for use as a main system with TH115L or TH118L
- Computer aided design to optimize frequency and phase response
- Powder coated grill
- Durable Polyurethane textured base paint
- suitable for theatre ,television studio, multi-functional room and performance studio
Specifications
Acoustical specifications
Frequency Response(-3db):
280Hz-20kHz
Max SPL @ 1m:
Passive: 126dB/132dB(PEAK); Bi-amp: MF: 126dB/132dB(PEAK)； HF: 126dB/132dB(PEAK)
Dispersion (H x V):
TH306H/64: 60°x 40°; TH306H/94: 90°x 40°
Transducers
Compression driver:
1 x 1.75" HF
Midrange:
1 x 6" MF
Input/Output section
Input Connectors:
1 x NL8, 8-way binding post
Sensitivity (1W @ 1m):
Passive: 106dB (TH306H/64); 106dB (TH306H/94); Bi-amp: MF 106dB; HF 112dB
Processor section
Crossover frequencies:
2kHz-2.5kHz
Power section
Total Power:
100W(RMS); 200W(MUSIC); 400W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
15mm Plywood
Hardware:
24 x M10 Steel Mounting Point
Grille:
Durable Polyurethane textured paint Black powder coated grille
Color:
Black
Size
Dimension (W x D x H):
520 x 520 x 520mm / (20.5 x 20.5 x 20.5in)
Package Dimensions (W x D x H):
630 x 630 x 640mm / (24.8 x 24.8 x 25.2in)
Weight
Net Weight:
25 kg / 55.1 lb
Gross Weight:
37 kg / 81.6 lb
