Features
- High SPL and sensitivity
- 1 x 8” high power low frequency transducer
- 1 x 1” PEI diaphragm compression driver
- Passive configuration
- 140º x 140º wide angle coverage pattern
- I x NL4 connector
- Computer aided design to optimise frequency and phase response
- Multi purpose cabinet design for FOH or monitor use
- Use as a main system with or without sub speaker augmentation
- Suitable for speech and background music
- Flexible and easy-to install configurations (wall, ceiling, under balcony)
- U bracket included
- Combine with any ΣB or ΣJ Series high power sub speaker for extended low frequency, high quality music reproduction
- Powder coated grill
- Durable Polyurethane textured base paint, white available
- 1 x NL4 connector included in packaging
Specifications
Acoustical specifications
Frequency Response(-3db):
85Hz-19kHz
Max SPL @ 1m:
113dB/119dB(PEAK)
Dispersion (H x V):
140° x 140°
Transducers
Compression driver:
1 x 1" HF Compression Driver
Woofer:
1 x 8" LF
Input/Output section
Input Connectors:
1 x NL4
Sensitivity (1W @ 1m):
93dB
Processor section
Crossover frequencies:
2.5kHz
Power section
Total Power:
100W(RMS); 200W(MUSIC); 400W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
258 x 247 x 408mm / (10.2 x 9.7 x 16.1in)
Package Dimensions (W x D x H):
617 x 337 x 508mm / (24.3 x 13.3 x 20in)
Weight
Net Weight:
8.2 kg / 18.1 lb
Gross Weight:
22 kg / 48.5 lb
