Features
High SPL and sensitivity
2 x 15” high power low frequency transducer
1 x 3” titanium diaphragm compression driver
Drived by one amplifier
60°X40° width direction to get more widely enlarge capability
With computer optimize simulated design to get better grquency and phase features
Multiple flexible installation methods
Suitable for full sound field enlarge, club and dancery etc publics using
Suitable for any big sound engineering project or enlarge, returning listen, repair listen of fluxion performance system
Used for high quality output replaying music, can be assorted with ΣB115H, ΣB118D, ΣB218 high capacity bass box
Specifications
Acoustical specifications
Frequency Response(-3db):
45Hz-16kHz
Max SPL @ 1m:
126dB/132dB(PEAK)
Dispersion (H x V):
60° x 40°
Transducers
Compression driver:
1 x 3" HF Compression Driver
Woofer:
2 x 15" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
98dB
Processor section
Crossover frequencies:
1.7kHz
Power section
Total Power:
750W(RMS); 1500W(MUSIC); 3000W(PEAK);
Nominal Impedance (Ohm):
4Ω
Physical specifications
Cabinet/Case Material:
Wedge shape
Hardware:
Speaker stand
Handles:
2 x Wooden handles
Grille:
Cabinet coated by Polyurethane paint; grille is powder coated
Color:
Black
Size
Dimension (W x D x H):
550 x 660 x 1070mm / (21.7 x 26 x 42.1in)
Package Dimensions (W x D x H):
1185 x 670 x 770mm / (46.7 x 26.4 x 30.3in)
Weight
Net Weight:
63 kg / 138.9 lb
Gross Weight:
67.5 kg / 148.8 lb
ΣS2153 Application
ΣS2153 Installation
ΣS2153 Parts
ΣS2153 Cases
ΣS2153 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 ΣS2153 Datasheet | 1.0 |  | 200KB | 2024-11-23 02:24:08 |
| β3_ΣS2153_PA_Chinese_Manual | 1 |  | 2935.6KB | 2018-07-12 02:25:39 |
| β3_ΣS2153_PA_English_Manual | 1 | | 2460.54KB | 2018-07-12 02:25:39 |
| β3_ΣS2153II_PA_Chinese_Manual | 1 | | 2768.44KB | 2018-07-12 02:25:39 |
| β3_ΣS2153II_PA_English_Manual | 1 | | 2561.53KB | 2018-07-12 02:25:39 |
