Features
- High output SPL and sensitivity
- Speakon input connectors
- Integrated pole mount adaptor at bottom
- Portable system (stand), or permanent installation (wall, ceiling, under balcony)
- Suitable for use as a main system with or without sub speaker augmentation
- Powder coated protective grill
- Durable Polyurethane textured base paint
Specifications
Acoustical specifications
Frequency Response(-3db):
50Hz-19KHz
Max SPL @ 1m:
112dB/118dB(PEAK)
Dispersion (H x V):
80° x 70°
Transducers
Compression driver:
1 x 1.3" HF
Woofer:
1 x 10" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
90dB
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
Plywood
Hardware:
12 × M10 hanging point
Handles:
2 × Wooden handles
Grille:
Cabinet coated by Polyurethane paint; grille is powder coated
Color:
Black
Size
Dimension (W x D x H):
335 x 335 x 530mm / (13.2 x 13.2 x 20.9in)
Package Dimensions (W x D x H):
425 x 425 x 630mm / (16.7 x 16.7 x 24.8in)
Weight
Net Weight:
15.7 kg / 34.6 lb
Gross Weight:
17.6 kg / 38.8 lb
