Features
- High output SPL and sensitivity
- 1 x 12” high power Neodymium transducer with 75mm voice coil
- 1 x 3” Neodymium compression driver
- Passive configuration
- 45º x 45º controlled coverage pattern
- Computer aided design to optimise frequency and phase response
- Cabinet design for monitor use
- Portable system or for permanent installation
- For ease of cabling there is an NL4 connector on either side of the speaker
- Powder coated grill with foam backing
- Durable Polyurethane textured base paint
- 1 x NL4 connector included in packaging
Specifications
Acoustical specifications
Frequency Response(-3db):
80Hz-16kHz
Max SPL @ 1m:
121dB/127dB(PEAK)
Dispersion (H x V):
45° x 45°
Transducers
Compression driver:
1 x 3" HF Compression Driver
Woofer:
1 x 12" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
97dB
Processor section
Crossover frequencies:
1.8kHz
Power section
Total Power:
350W(RMS); 700W(MUSIC); 1400W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Cabinet/Case Material:
15mm Birch Plywood
Handles:
2 x Wooden handles
Grille:
Polyurethane-based painting. Steel grille is coated by dots to provide strong ultra-Weatherability
Color:
Black
Size
Dimension (W x D x H):
410 x 548 x 450mm / (16.1 x 21.6 x 17.7in)
Package Dimensions (W x D x H):
650 x 500 x 510mm / (25.6 x 19.7 x 20.1in)
Weight
Net Weight:
19.3 kg / 42.5 lb
Gross Weight:
21.5 kg / 47.4 lb
