Features
- Build-in amplifier, build-in MP3 player
- Compact light weight design, versatile sound reinforcement.
- High output SPL and sensitivity.
- Built-in digital amplifier provides abundant energy.
- Heavy duty protective front grill.
- Pole mount socket for speaker stand.
- Suitable as a main system with or without sub speaker.
Specifications
Acoustical specifications
Frequency Response(-3db):
50Hz-20kHz
Max SPL @ 1m:
122dB/128dB(PEAK)
Dispersion (H x V):
85° x 75°
Transducers
Compression driver:
1 x 1.4" Driver
Woofer:
1 x 15" Woofer
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
XLR K3P
Power section
Total Power:
500W(RMS); 1000W(MUSIC); 2000W(PEAK);
Nominal Impedance (Ohm):
8Ω
Voltage range:
110V/220V
Standard compliance
CE marking:
Yes
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
485 x 458 x 727mm / (19.1 x 18 x 28.6in)
Package Dimensions (W x D x H):
545 x 515 x 800mm / (21.5 x 20.3 x 31.5in)
Weight
Net Weight:
23.5 kg / 51.8 lb
Gross Weight:
26.5 kg / 58.4 lb
V152a-MP3 Application
V152a-MP3 Installation
V152a-MP3 Parts
V152a-MP3 Cases
V152a-MP3 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 V152a-MP3 Datasheet | 1.0 |  | 200KB | 2025-02-22 08:38:41 |
