Features
- High output SPL and sensitivity
- High quality music reproduction
- Heavy duty protective grill
- Injection molded
- 2 x NL4 connector
- Cabinet design for FOH and Monitor use
- Suitable for use as a main system with or without sub speaker augmentation
- Portable system (stand), or permanent installation (wall, ceiling)
- Weatherproof version available
- Monitor kit - optional
Specifications
Acoustical specifications
Frequency Response(-3db):
60Hz-20kHz
Max SPL @ 1m:
120dB/126dB(PEAK)
Dispersion (H x V):
90° x 40°
Transducers
Compression driver:
1 x 1.7" HF
Woofer:
1 x 12" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
95dB
Power section
Total Power:
300W(RMS); 600W(MUSIC); 1200W(PEAK);
Nominal Impedance (Ohm):
8Ω
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
415 x 371 x 609mm / (16.3 x 14.6 x 24in)
Package Dimensions (W x D x H):
465 x 435 x 680mm / (18.3 x 17.1 x 26.8in)
Weight
Net Weight:
18 kg / 39.7 lb
Gross Weight:
20 kg / 44.1 lb
N12 Application
N12 Installation
N12 Parts
N12 Cases
N12 Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 N12 Datasheet | 1.0 |  | 200KB | 2024-12-23 14:26:57 |
| β3_N12_Plastic_SpeakerManual | 1 | | 1350.29KB | 2018-07-12 02:25:39 |
