Features
- Build-in amplifier.
- Compact light weight design, versatile sound reinforcement.
- High output SPL and sensitivity.
- Built-in digital amplifier provides abundant energy.
- Heavy duty protective front grill.
- Pole mount socket for speaker stand.
- Suitable as a main system with or without sub speaker.
Specifications
Acoustical specifications
Frequency Response(-3db):
55Hz-20kHz
Max SPL @ 1m:
122dB/128dB(PEAK)
Dispersion (H x V):
85° x 75°
Transducers
Compression driver:
1 x 1.4" Driver
Woofer:
1 x 12" Woofer
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
XLR
Power section
Total Power:
500W(RMS); 1000W(MUSIC); 2000W(PEAK);
Nominal Impedance (Ohm):
8Ω
Voltage range:
110V/220V
Standard compliance
CE marking:
Yes
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
415 x 385 x 629mm / (16.3 x 15.2 x 24.8in)
Package Dimensions (W x D x H):
465 x 435 x 680mm / (18.3 x 17.1 x 26.8in)
Weight
Net Weight:
17 kg / 37.5 lb
Gross Weight:
19.5 kg / 43 lb
